Hydraulic lifting system with 2 and 4 columns certified for the transport of goods accompanied by a person, with a load capacity ranging from 3000 kg to 5000 kg.
Decree-Law for Freight Only
It optimizes the loading area for goods only and is suitable for connecting multiple levels with attendant staff present on the floor. Ability to reach capacities up to 5000Kg or higher.
DL SPB with an operator on board
Allows the attendant to operate the system on board in complete safety. In addition, the extremely sturdy platform is suitable for transit and transportation of a forklift accompanied by the operator.
DL 2 Smart two-column freight elevator up to 3000 kg
Scope
3000 KG
Max stroke
16 m
Floor depth
2500 mm
Flatbed width
5200 mm
Pit
250 mm
Minimum header
2400 mm
Max stops
5
Power supply
Three-phase
Basic motor
5.5 kW
DL 2 two-column hoist up to 4000 kg
Scope
3000/4000 KG
Max stroke
16 m
Floor depth
3000/2500mm
Flatbed width
6000/4500 mm
Pit
300 mm
Minimum header
2400 mm
Max stops
5
Power supply
Three-phase
Basic motor
5.5 kW
DL 4 four-column lifts up to 5000 kg
Scope
4000/5000 KG
Man on board
Certified up to 4000 kg
Max stroke
16 m
Floor depth
3000 mm
Flatbed width
6000 mm
Pit
1150 mm
Minimum header
2200 mm
Max stops
5
Power supply
Three-phase
Basic motor
5.5 kW
